VDE Approved T8 LED Tube
VDE Approved T8 LED Tube Specification:
VDE Approved T8 LED Tube Application:
1. Instead of the indoors ceiling light
2. School/Universities/Hospital
3. Conference/Meeting room,Show Room
4. Commercial Complexes
5. Factories/Offices
6. Super markets
7. Residential/Institution buildings
ENELTEC remind you:If you want to know more about other products, please contact us.
1200mm 18w T8 led tube lighting
1200mm 18w T8 led tube lighting Specification:
| Power | 18W |
| Input Voltage | AC100-240V |
| Frequency Range | 50Hz–60Hz |
| Light Source | 2835LED |
| Led Quantity | 96PCS |
| Luminous Flux | 1800lm |
| Luminous Efficiency | 90-100lm/w |
| Material | Aluminum + PC |
| Cover | Milky white |
| Base | G13 |
| Color Rendering Index(CRI) | Ra≥80 |
| Beam angle | 180°/240° |
| Working Temperature | -20°C~40°C |
| Color Temperature | Warm White(WW): 3000-3500K |
| Pure White(PW):4000-4500K | |
| Cool White(CW):6000-6500K | |
| Certificates | CE, RoHS, FCC,UL |
| Warranty | 3 years |
| Life-span | 50000h |
| Dimension | 26*1200MM |
| Weight | 0.53KG |
Features of 18w 1200mm t8 led tube
1. This product meets the standard of CE, ROHS,FCC,UL certification.
2. With internal No-isolated power supply.
3. Round and the elliptical tube are available.
4. Use the most mature international well-known LEDSMD2835 as the light source, which can ensure the led tube brightness and long lifespan, also can reduce the light decay.
5. Use the high quality aluminum PCB for LED’s better heat dissipation.
6. High-grade PC cover with nice light transmittance (> 95%), Transparent PC cover and milky PC cover are available.
7. No mercury, lead or other hazardous materials; no radiation, no electromagnetic radiation, no frequency
flash, instant start, no humming.
Business of 18w 1200mm t8 led tube Our LED lights sell very well in Europe such as Poland,Sweden, Germany, Great Britain, Hungary, Austria, Portugal and South America Countries such as Brazil etc.
Welcome to our factory and negotiate business. We trust we will be your best supplier in China.
ENELTEC remind you:If you want to know more about other products, please contact us.
1800lm 1200mm Taiwan chip 18w led tube
1800lm 1200mm Taiwan chip 18w led tube Specification:
| Working Voltage: | AC85-265V | |||
| Power Consumption: | 18W | |||
| Body Material: | Aluminum+PC | |||
| Luminus Flux: | 1600-1900lm | |||
| LED Type and Quantity: | 96 pcs 2835 taiwan chip | |||
| Life span: | ≥50,000Hrs | |||
| Inner package: | 40*40*1220mm | |||
| G.W | 589g | |||
| Size: | 26x1200mm | |||
| Beam angle: | 120° | |||
| Warranty: | 2 years | |||
1800lm 1200mm Taiwan chip 18w led tube Feature:
1. LED: Epistar 2835smd, 0.2w/pcs, 24lm/pcs. super bridghter, comparing with normal 3528smd, more brighter and with good heat dissipation.
2.Driver: high effiency, PF: >0.95, 3years warranty
3.PCB:good heat dissipation aluminum PCB.
4. Ciruit design: Singel designed , 1pcs LED damage, would not affect other LED.
5. Aluminum Body: stronger aluminum shell with plate silica gel pad under PCB
6.Package: 2type for you to make a choice
7. Test: Material test before production contain driver, LED and other material. then 24hours aging test.
ENELTEC remind you:If you want to know more about other products, please contact us.
Factory price 600mm t8 10W led tube
Factory price 600mm t8 10W led tube Product features:
1.Energy saving: low power consumption, low heat, high level of brightness, uniform light-emitting, energy-saving about 50%
2. Long lifespan: the normal lifespan of LED tubes is above or equal to 50.000H
3.Warranty time : 3 years(the range of colour temperature:2800K-6500K .
4.Certificates: TUV ,CE ,and ROHS.
5. No twinkling: rapid start, steady work, no noise, no twinkling can effectively protect the eyes,conforming to CE.
6. Special circuit design: ensuring that each LED to work independently, the damage of single LED has no influence on the whole ,conforming to ROHS.
7. Green and environmentally-friendly: LED tube has no ultraviolet or infrared radiation, containing no mercury, lead and heavy metal.
8. Color rendering index(CRI)is optional , for example we can make Ra=80 .
9.Have been exported to the germany many times and good effects have been received.
Specifications
No.1 100% energy-Saving
No.2 Long lifetime up to 50000h with 3 years warranty
No.3 factory price
ENELTEC remind you:If you want to know more about other products, please contact us.
LED lights radiator is a critical component of its shape volume cooling surface area should be designed to be just right, the radiator is too small, LED lights county operating temperature is too high, affecting the LED luminous efficiency and lifetime of the radiator is too large, the consumption of materials to increase product cost and weight of the product less competitive. Design appropriate LED lamps radiator is essential. Design of the radiator has the following components.
1) Confirm the cooling power of LED Lamps. The parameters are: metal thermal conductivity than the hot metal chip thermal heat sink thermal resistance ambient air thermal resistance, etc.
2) Determine the type of heat used (natural convection cooling heat pipe cooling winds and jet refrigeration cooling mode). From the cost is relatively low cost of natural convection, forced air cooling medium high heat pipe cooling, jet refrigeration highest cost.
3) Verify the LED lamps allow the maximum operating temperature (ambient temperature plus temperature rise permitted lamps).
4) Calculate the volume of the heat sink area, and determine the shape of the radiator.
5) The radiator with LED lights combined into a complete lighting and powered T for more than 8h at room temperature 39 ℃ ~ 40 ℃ environment temperature checks to see if the lamps meet the cooling requirements to test calculations are correct, does not satisfy the conditions of use as will have to recalculate and adjust parameters
6) The radiator to do with the lampshade waterproof and dustproof seal between the radiator lampshade to pad aging of the rubber pads or silicone rubber pad with stainless steel bolts do sealed waterproof and dustproof.
outdoor 80w LED flood light with UL CUL cert
outdoor 80w LED flood light with UL CUL cert Specification
Input Voltage:AC 100~240/270Vac,1.7A Max
Power: 150W(replace to 300~320W halogen or Sodium Lamp)
View Angle:45degree
IP Degree: IP65
Weight: 8.2kg
Luminosity: 10000~ 12300Lm
CE & RoHs cUL,UL
DLC is pending
Warranty: 3 years
LED flood light Feature
High performance LED design delivering up to 100 lumens per watt
New stylish industrial design
IP65
LED flood light Application
The New floodlight is designed to efficiently light in any large interior space such as heavy industrial settings,work shop,factory,high-way check point,exhibition center,gym,wharehouse,parking lot,etc
Operating Temperature : -40°C~40°C
ENELTEC remind you:If you want to know more about other products, please contact us.
50W 4000lm outdoor led flood light
50W 4000lm outdoor led flood light Specification:
Item NO: VF5001
Casing : AL & Glass
Power: 50W
Input Voltage: AC85-265V
Color Temperature: 2700-3100K / 5700-6300K / 3800-4500K
Luminous Flux: 3500-4000LM
Surface color: Silver
LED Source: 1*50W (COB)
IP65
Dimension: 290*240*150mm
Buy recommendation
1. Our all items are 100% authentic, please provide details of the address before purchase, so we can calculate the shipping discounts and the best transportation.
2. According to the customer’s requirement, different specifications of the items can be mixed shipments and lower freight.
3. Only wholesale, if require samples, please contact us. If you have any questions or suggestions, please Contact us freely.
ENELTEC remind you:If you want to know more about other products, please contact us.
waterproof driver 50w led flood light
waterproof driver 50w led flood light Specification:
| Power | 50W |
| LED Chip | Bridgelux |
| LED Quantity | 1PC COB |
| Lamp Luminous Efficiency | 90 lm/w |
| Input Voltage | AC 85~265V |
| Power Factor | > 0.95 |
| Power Efficiency | > 90% |
| Color Rendering Index | Ra>70 |
| Correlated Color Temperature | 2700-7000K |
| Angle of Reflector | 45° or 90° or 120° |
| Working Temperature | – 20 ~ +45°C |
| IP Grade | IP65 |
| Life Span | 50,000Hrs |
| Connecting Wire | VDE/SAA |
| Lamp Shell Color | Black or Silvery |
led flood light Feature:
1.SAA/C-Tick/CE/RoHS approved, high quality guaranteed outdoor saa and c-tick listed led flood light 50w .
2.Imported original (Bridgelux etc); Stable driver (Meanwell etc); High quality light housing.
3.48Hrs Auto Aging test time, every lamp will be checked by QC before packed.
4.Reliable quality & credit, 3 years warranty and 50,000 hours lifespan. 50w led flood light for billboards saa
5.Tough box will be designed for the items, keep the safety of goods in the transportation
LED Flood light Certificates :
SAA,C-Tick, CE, RoHS. From 10-200W 50w led flood light for billboards saa.
ENELTEC remind you:If you want to know more about other products, please contact us.
120w gas station led flood light
led flood light specifications
| Power | 120W | |||
| Input voltage | AC 85-265V/50-60Hz | |||
| LED source | Bridgelux | |||
| LED QTY | 120pcs | |||
| Total harmonic distortion | ≤9% | |||
| Power factor | >0.98 | |||
| LED efficiency | 115-125lm/w | |||
| LED lamp luminous efficiency | 90-95Lm/W | |||
| Color temperature | WW: 2700-3500K | |||
| PW: 4500-5500K | ||||
| CW: 6000-7000K | ||||
| CRI(Ra) | ≥70 | |||
| IP grade | IP65 | |||
| LED junction temperature | ≤70°C | |||
| Ambient temperature | -40°C—45°C | |||
| Material | Aluminium + tempered glass | |||
| Lifepsan | 50,000hrs | |||
| Warranty | 3years | |||
led flood light details
1. All adopt Bridgelux LED chip.
2. Lumen efficiency of leds can be 115-125Lm/W.
3. Passed CE, RoHS, FCC, EMC, LVD certifications.
4. We have patent on the design.
5. 3 years warranty for Mean Well driver, 2 years for BEEQOO driver, 5 years for LED chip.
6. Emitting colors available: warm white, pure white, cool white, red, yellow, green, blue, RGB etc.
led flood light applications
Apply to workshop, gymnasium, square, advertisement, high building, gardening and other similar places requiring lighting.
ENELTEC remind you:If you want to know more about other products, please contact us.
LED is recognized as the 21st century “green light”. In the road lighting, tunnel lighting, public lighting and other functions particularly highlighted significance of lighting applications. Data shows that if the current 1 /3 of the incandescent lamp were replaced by LED lights, each of the country can save 100 billion kWh of electricity, which could be equivalent to the Three Gorges project generating capacity a year. The following summarizes the green LED lighting features are: high energy saving, long life, many changes, environmental protection, high tip.
High energy performance is DC drive, electro-optical power conversion close to 100%, saving more than 80% energy with the traditional energy sources;
Long life performance show that LED lighting is not exiting burn, heat deposition, and the light fades and other shortcomings, it called longevity lamp. The life is up to 60,000 to 100,000 hours, more than 10 times life than conventional light sources.
Performance of many changes are red, green , blue three color theory, under the control of computer technology to make three kinds of colors with 256 gray scale , and any mix , produce 16,777,216 colors;
Lee Green showed neither heat nor radiation, and recyclable waste, no pollution, cold light source, and it is safe touch;
High point performance shows that with online programming, unlimited upgrades, and flexible features as a low voltage microelectronic product.
Looking to the future , LED lighting products will be used in a broader effort to lighting field, fight with solar, wind and other ” green energy ” by combining more effectively address regional energy crisis and environmental problems , as promote regional economic development boost.
