How to test the reliability of high power led driver



How to test the reliability of high power led driver



So, really high quality LED driver power supply should have what kind of features or to meet those requirements? Tektronix summed up the following main aspects:



(1) high reliability and life: the life of the drive power to the life of the LED relative to adaptation, in particular, like the drive power of the high power led driver installed at high altitude, maintenance inconvenient, the maintenance cost is also large;

(2) High efficiency: the structure of power supply installed in the LED lighting, which is especially important. LED luminous efficiency of high power led driver temperature decreases, so the LED heat dissipation is very important. High efficiency power supply, the loss power, heat lamps, reduces the temperature rise of the lamps is beneficial to delay the LED light failure.

(3) high power factor: With the increasing demands of the community’s quality of power supply, people are increasingly concerned about the electrical equipment of power quality and harmonics. Such as the EU has issued standards require power greater than 25W power supply must have a power factor correction circuit. And many other countries for 30 ~ 40W LED driver power supply, It is said that soon will also may power factor of a certain indicator.

(4) constant current driver: It is now common, there are two: one is a constant voltage source for the constant current source, each constant current source separately to each high power led driver. In this way the combination of flexible, all the way to the LED fault, does not affect the other LED’s work (led high bay lights), but the cost will be slightly higher.



How to improve the power factor of high power gu10 led



How to improve the power factor of high power gu10 led



The measurement of drive power, input power, power factor and harmonic There are many ways to use power analysis capabilities of the Tektronix oscilloscope products you can easily achieve these power quality measurements. Channel to measure the input voltage and channel all the way to measure the input current with the oscilloscope’s built-in PWR power analysis software, all power quality parameters can be displayed directly on the screen.



Drive power efficiency of high power gu10 led and power within the switching losses are directly related. Reduce the loss of power devices is not only improved power efficiency, but also a key factor to improve the thermal stability and reliability. However, the switching losses of power device measurement is not easy to achieve. As the device turns on and off state of the voltage amplitude difference between high power gu10 led and led high bay lights in such a large dynamic range can not accurately measure the tiny voltage-state conduction losses is no way of measuring.



For high speed switching power devices, can only be multiplied by the voltage and current transient power approach to computing power. Then the voltage and current must be the same moment of the waveform, otherwise the error is huge. However, the principle and structure of the voltage and current probes for high-speed switching signal time delay. If you can not accurately correct for high power gu10 led, the measurement results of the oscilloscope is not credible. Tektronix oscilloscope power measurement scheme not only has a comprehensive test function of the switching loss, also has a powerful probe calibration function to completely eliminate the time delay error.

PWM analysis for high power led bicycle lights



PWM analysis for high power led bicycle lights



Home truly energy-efficient LED lighting products, ultimately to have a dimming feature, Europe and the United States and other high-end market demand in other countries and markets in the future will be the gradual popularization. The latest technology in LED dimming PWM, by a different pulse width of the PWM signal to control the ratio of the power device is switched on and off, thereby to adjust the output luminous flux. Compared to other dimming and PWM dimming without changing the LED current flowing through the size, the lamps will not cast, but also to avoid the loss of resistance dimming energy, maintaining the high efficiency of high power led bicycle lights.



Tektronix AFG3000 any, waveform generator can easily generate a PWM signal, the user can change the PWM changes the form of the output pulse width ratio and variation, all the operation only on the panel pressed a button, the impedance of the generator built-in the adjustment function can be adapted to the circuit needs.



Ripple is added to the AC voltage on the DC output voltage, the led high bay power supply testing is an important measurement parameters. Ripple current increases, power costs are lower, but the light output would be affected, and will improve the LED junction temperature and thus affect the LED performance, or even seriously reduce the life of the high power led bicycle lights (experience has shown, the junction temperature is increased by 10 ℃ life is shortened by half). Therefore, accurate measurement of the ripple is very important. Tektronix oscilloscope power test program has a ripple measurement can be a key to complete the ripple parameters were measured. For high-end applications, the Tektronix TCPXX Series current probes are available as low as 1mA of ripple current measurement accuracy, cost-effective probe for selection for cost-sensitive applications.
