QOD L – Ceiling luminaires – Indoor LED luminaires
Electrical data
| Nominal wattage |
28.00 W |
| Operating mode |
Electronic control gear (ECG) |
Light technical data
| Color temperature |
3050 K |
| Beam angle |
86 ° |
| Luminous flux |
900 lm |
Dimensions & weight
| Length |
220.0 mm |
| Width |
220.0 mm |
| Height |
11.0 mm |
Colors & materials
| Body material |
Plastic |
| Product color |
White |
| Cover material |
Polycarbonate (PC) |
| Reflector material |
Polycarbonate (PC) |
Temperatures
| Ambient temperature range |
…+25 °C |
Additional product data
| Number of lighting outlets |
1 |
| Equipment |
LED Products |
| Equipped with lamp |
Yes |
| New article |
NEW |
Capabilities
| Type of installation |
Clip |
| Dimmable |
No |
| Color management (RGB) |
No |
| With on/off switch |
No |
| Type of connection |
Plug transformer |
Certificates & standards
| Standards |
CE |
| Protection class |
insulation class II (safety insulation) |
| Type of protection |
IP20 |
| Protection against ignition and fire |
F, MM |
Country specific categorizations
| Order reference |
41031 |
LED Floater Headline
.000 K (Warm White)
Type of mounting.
Company Press Career Sustainability
Back to OSRAM homepage
Applications
Products
Tools & Services
Trends & Knowledge
Advanced full-text search
Products – LED technology, important data at a glance
Zoom image
QOD L
Product data sheet
Add to notepad
Technical data
Expand
Graphics and application images
Expand
Packaging imageZoom image
Application PicturesZoom image
Application PicturesZoom image
Application PicturesZoom image
Packaging information
Expand
Country-specific information
Expand
Print this page
Jump to top
Global OSRAM websites OSRAM in the Social Web
Share Sitemap
Imprint Terms of use Privacy Policy Contact ? 2013:
Indoor LED luminaires
Ceiling luminaires
QOD L
QOD L
Zoom in
Zoom out
Resize
Product benefits
Energy saving thanks to LED technology
High brightness thanks to LED technology
Stylish design
Quick and simple installation (Plug & Light)
Product features
Extremely low profile
Color temperature: adhesive tape or srews
Family data sheet
Product family, All rights reserved: OSRAM GmbH: 3
| EAN code |
Packaging unit
Pieces per unit |
Dimensions
l x w x h |
Gross weight |
Volume |
| 4008321974952 |
Folding carton box
1 |
282 mm x 49 mm x 282 mm |
1062.00 g |
3.90 dm³ |
| 4008321974969 |
Shipping carton box
4 |
366 mm x 242 mm x 358 mm |
4992.38 g |
31.71 dm³ |
