| Rated wattage | 2 W |
|---|---|
| Nominal wattage | 2 W |
| Nominal voltage | 100…240 V |
| Operating frequency | 50…60 Hz |
| Luminous intensity | 100 cd |
|---|---|
| Beam angle | 20 ° |
| Nominal luminous flux | 25 lm |
| Rated luminous flux | 25 lm |
| Color temperature | 3300 K |
| Color rendering index Ra | 80 |
| Starting time | 0.0 s |
| Overall length | 74.0 mm |
|---|---|
| Diameter | 50.0 mm |
| Outer bulb | PAR51 |
| Lamp mercury content | 0.0 mg |
|---|---|
| Mercury-free | Yes |
| Nominal lamp life time | 20000 h |
|---|---|
| Rated lamp life time | 20000 h |
| Base (standard designation) | E27 |
|---|---|
| Footnote used only for product | All technical parameters apply to the entire lamp/Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value |
| Dimmable | No |
|---|
| ILCOS | DRPAR-2-100/240-E27-20 |
|---|---|
| Order reference | 8031001 |
.
Company Press Career Sustainability
Back to OSRAM homepage
Applications
Products
Tools & Services
Trends & Knowledge
Advanced full-text search
Products – LED technology. LED Floater Headline
,
LED STAR DECO PAR16
LED STAR DECO PAR16
Zoom in
Zoom out
Resize
Product benefits
Very low energy consumption
Extremely long life
Efficient production of colored light in saturated colors
No UV and near-IR radiation in the light beam
Shockproof and vibration-proof thanks to LED technology
Low heat generation
Low energy consumption
Areas of application
Spotlighting for color accents
Display cabinets and shop windows
Retail outlets and exhibition rooms
Spotlighting heat-sensitive objects such as food.
Lamps
Consumer decorative LED reflector lamps:.
Outdoor [,
Outdoor use in outdoor luminaires only (minimum IP65)
Product features
Affordable LED lamp for line voltage
Not suitable for use with dimmers
Mercury-free lamps
Equipment / Accessories
Equipped with successful OSRAM high-power Golden DRAGON LEDs Reduce text
Family data sheet
Product family, OSRAM GmbH.1 MB
Packaging information
Expand
Print this page
Jump to top
Global OSRAM websites OSRAM in the Social Web
Share Sitemap
Imprint Terms of use Privacy Policy Contact ? 2013. All rights reserved. etc. plants, important data at a glance
10 20° 2 W/865 E27
10 20° 2 W/830 E27
10 20° 2 W/765 GU10
10 20° 2 W/765 E27
10 20° 2 W/830 E27
10 20° 2 W/830 GU10
Scroll to left
Scroll to right
Zoom image
LED STAR DECO PAR16 10 20° 2 W/830 E27
Product data sheet
Add to notepad
Technical data
Expand
Graphics and application images
Expand
Downloads
Expand
File Type Size
mov
Product movie
LED COMPETENCE SPOT 2009 (H264) mov 96, plants. etc.] Show all
Product benefits
Very low energy consumption
Extremely long life
Efficient production of colored light in saturated colors
No UV and near-IR radiation in the light beam
Shockproof and vibration-proof thanks to best LED Bulb technology
Low heat generation
Low energy consumption
Areas of application
Spotlighting for color accents
Display cabinets and shop windows
Retail outlets and exhibition rooms
Spotlighting heat-sensitive objects such as food.:
| EAN code | Packaging unit Pieces per unit |
Dimensions l x w x h |
Gross weight | Volume |
|---|---|---|---|---|
| 4008321924421 | Blister 1 |
125 mm x 57 mm x 79 mm | 55.00 g | 0.56 dm³ |
| 4008321924438 | Shipping carton box 6 |
312 mm x 136 mm x 158 mm | 519.33 g | 6.70 dm³ |
| 4008321332813 | Shipping carton box 36 |
498 mm x 286 mm x 328 mm | 3801.00 g | 46.72 dm³ |
