作者：Blade

Cross-strait release: Integrated double-ended LED light safety requirements

For the LED industry, “integrated double-ended LED light safety requirements”, in fact, specification is the LED lamp, replace the traditional part of fluorescent tubes, the need for a common safety standards.

Cross-strait-release:-Integrated-double-ended-LED-light-safety-requirements

As the LED lamp has a single-ended power and double-ended power two, the former is relatively safe in the design, which may cause the risk of electric shock, so do not accept the European and American markets are set to drive the dual power, a certain limit. However, markets such as Italy are acceptably double-ended.

The current cross-strait industry for double-ended LED lamp safety specification is not perfect, but the international community has the corresponding security standards, such as the 2014 IEC replacement for double-ended LED lamp safety standards, has taken into account the consumer to replace their own LED lamp when the security.

The current mainland market, the number of LED tubes a year to about 500 million in 2015, the future of this replacement market will continue to expand the scale, and the two sides for the double-ended LED lights do a common safety requirements, overall is a good thing.

T8, T5 tube has launched single-ended power LED lamp manufacturers, but also the design of the corresponding fence stent to avoid re-wiring problem, is still the first-tier international manufacturers of products. The future popularity of lamp specifications in this regard, the market has yet to test the cost of consumer control and manufacturers.

6W A19 LED Light Bulbs 665 Lumens

6W A19 LED Light Bulbs 665 Lumens

6W A19 LED Light Bulbs 665 Lumens replace a 40-Watt incandescent bulb, fit fixtures with an E26 base, and last up to 50,000 hours. Our LED light bulbs consume 80% less energy than traditional incandescent and are affordably priced at up to 50% less than competitor bulbs.

6W A19 LED Light Bulbs 665 Lumens Specification:

Lamp Base E26
Bulb Type A19
Color Warm White
Color Temperature 2700K
Lumens 665Lm
CRI > 75
Lens Type White Frosted
Beam Angle 140
Dimmable? No
Features Shock Resistant
Power 8 Watts
Input Voltage 110 ~ 120VAC
Diameter 2.3 Inches
Length 4 Inches

6W A19 LED Light Bulbs 665 Lumens Features:

  • Replaces a traditional 60W incandescent bulb
  • Uses 80% less energy and lasts up to 50,000 hours
  • Affordably priced at up to 50% less than competitor LED bulbs
  • For indoor use in any standard household A19 base and fixture
  • Estimated lifetime savings of $221.00 with a yearly energy cost of $0.84 (based on 3 hours/day, $0.13/kWh)
  • Instant-on full brightness with little heat generation
  • Eco-friendly with no mercury or UV radiation
  • High quality
  • UL Listed
  • Warm White
  • Not dimmable

2W LED Filament candle Bulb E14 2700K 180LM

2W LED Filament candle Bulb E14 2700K 180LM

2W LED Filament candle Bulb E14 2700K 180LM Warm White 2700K Lumen Output (Brightness) 180 lm Non-dimmable.

2W LED Filament candle Bulb E14 2700K 180LM Specification:

Bulb Type/Shape: CANDLE
Body Material/ Finish: Glass Clear
Cap-Base/Socket SES E14
Power: 2 W
Luminous Flux (Lumen): 180 lm
Colour Designation: Warm White
Colour Temperature (Kelvin): 2700 K
Dimmable (?) NO
Colour Rendering Index (CRI): >80
LED Technology: COG LED Filament
IP Rating (Ingress Protection): IP20
Input Voltage: 220 -240 VAC
Input Frequency: 50Hz
Rated Lifetime: >20,000 hours
Beam Angle: 300° degrees
EU Energy Efficiency label: Class A+
Mercury Content: 0 mg
Power Factor Correction: >0.4
Operating Temperature: -20ºC to +45ºC
Overall Dimensions: Diameter: 35 mm
Length: 100 mm
Net Weight 50 g
Certifications: CE, EMC, RoHS, TUV

2W LED Filament candle Bulb E14 2700K 180LM Features:

80% lower on energy consumption compared to traditional bulbs
Long lifetime of 20,000 hours – Lasts 20 times longer than incandescent bulbs
V-TAC LED LIGHTING – ENERGY RATING A+Energy Rating: A+
Comfortable Warm White light. Colour Temperature: 2700K.
No mercury or other toxic content and No IR or UV radiation.
Equivalent to 20W traditional incandescent candle bulb
Environmentally friendly Sustainable Lighting technology for the Green economy
V-TAC LED LIGHTING – 2 YEARS WARRANTYInstant Full Light – No warm-up time as in the case of CFL bulbs
Covered in warranty for 2 years
Typical Applications:
V-TAC LED FILAMENT CANDLE E14 BULB
General Residential lighting
Hospitality lighting – hotels, guest houses, restaurants, cafes, tea rooms, bars, lounges
Ideal for classic and heritage style light fittings

A60 6W LED FILAMENT BULB B22 2700K 550LM

A60 6W LED FILAMENT BULB B22 2700K 550LM

A60 6W LED FILAMENT BULB B22 2700K 550LM Warm White 2700K Lumen Output (Brightness) 550 lm Non-dimmable.

A60 6W LED FILAMENT BULB B22 2700K 550LM Specification:

Bulb Type/Shape: A60 GLS
Body Material/ Finish: Glass Clear
Cap-Base/Socket BC B22
Power: 6 W
Luminous Flux (Lumen): 550 lm
Colour Designation: Warm White
Colour Temperature (Kelvin): 2700 K
Dimmable (?) NO
Colour Rendering Index (CRI): >80
LED Technology: COG LED Filament
IP Rating (Ingress Protection): IP20
Input Voltage: 220 -240 VAC
Input Frequency: 50Hz
Rated Lifetime: >20,000 hours
Beam Angle: 300° degrees
EU Energy Efficiency label: Class A+
Mercury Content: 0 mg
Power Factor Correction: >0.4
Operating Temperature: -20ºC to +45ºC
Overall Dimensions: Diameter: 60 mm
Length: 103.5 mm
Net Weight 80 g
Certifications: CE, EMC, RoHS, TUV

A60 6W LED FILAMENT BULB B22 2700K 550LM Features:

Chip-On-Glass (COG) LED Filament technology. Best of both worlds – classic charm and nostalgic appearance of filament bulb through advanced energy saving LED innovation.
80% lower on energy consumption compared to traditional bulbs
Long lifetime of 20,000 hours – Lasts 20 times longer than incandescent bulbs
V-TAC LED LIGHTING – ENERGY RATING A+Energy Rating: A+
Comfortable Warm White light. Colour Temperature: 2700K.
No mercury or other toxic content and No IR or UV radiation.
Equivalent to 40W traditional incandescent bulb
Environmentally friendly Sustainable Lighting technology for the Green economy
V-TAC LED LIGHTING – 2 YEARS WARRANTYInstant Full Light – No warm-up time as in the case of CFL bulbs
Covered in warranty for 2 years

GU10 3.5W 40D 260lm LED Bulb

GU10 3.5W 40D 260lm LED Bulb

GU10 3.5W 40D 260lm LED Bulb Equivalent to 35W Warm white light 2700K Mains Voltage 230 VAC Cap-base: GU10 Beam Angle 40º Dimmable.

GU10 3.5W 40D 260lm LED Bulb Specification:

Cap-Base/Socket: GU10
Bulb Design/Finish: PAR16 Spot lens
Wattage: 3.5 W
Wattage Equivalent: 35 W
Luminous Flux: 280 lumen
Luminous Flux in 90º Cone: 260 lumen
Luminous Intensity: 600 cd
Colour Designation: Warm White
Colour Temperature 2700 K
Colour Code: 827
Colour Rendering Index (CRI): >80
Luminous Efficacy: 74.29 Lm/W
Dimmable (Y/N)?: YES
Beam Angle: 40 degrees
Starting Time <0.5 sec (fast start)
Voltage: 220-240V
Power Factor: 0.5 (min)-
Lamp Current: 20mA
Rated Lifetime: 35,000 hr
EU Energy Efficiency label: Class A+
Mercury Content: 0 mg
Operating Temperature Range: -20ºC to +45ºC
Bulb Diameter / Width: 50 mm
Overall Length: 55 mm
Net Weight: 36 g

GU10 3.5W 40D 260lm LED Bulb  Features:

Class A++ Energy Efficiency achieved through advanced LED technology
Ideal replacement for GU10 halogen spots – Up to 90% energy saving
Warm White halogen-like light: Colour Temperature: 2700K
Excellent colour rendering: Colour Rendering CRI: 80.
Very low maintenance cost and ideal for hard-to-reach areas. Long lifespan of 35,000 hours
Short pay-back time – depends on number of hours per day with lamps on
High quality design, Robust housing. Shockproof.
Environmentally Sustainable: No mercury or hazardous materials, No UV or IR. No heat from light source. Low carbon footprint
LED technology is excellent for light sensitive objects
Dimmable with compatible dimmers
Ideal Applications: Where light is always or mostly ON such as Receptions, Lobbies, Corridors, Stairwells. Suitable for indoor general lighting and accent lighting.

12W Sensor Switched LED Flood light

12W-Sensor-Switched-LED-Flood-light

12W Sensor Switched LED Flood light with PIR motion detector in Black housing 198 LEDs system IP44 rated for outdoor Lumen Output 720 lm Cool White light 6700K.

12W Sensor Switched LED Flood light Specification:

Power: 12W
Luminous Flux (Lumen): ≥720 lm
Colour Designation: COOL WHITE
Colour Temperature (Kelvin): 6700K
LED Technology: 198 LEDs system
IP Rating (Ingress Protection): IP44
Protection Class: I
Input Voltage: 230-240 VAC
Input Frequency: 47Hz – 63Hz
Rated Lifetime: 50,000 hours
Beam Angle: 120° degrees
EU Energy Efficiency label: Class A
Mercury Content: 0 mg
Operating Temperature: -20ºC to +40ºC
Sensor Type Passive infrared (PIR)
Floodlight  Swivelling Range: 180º
Floodlight Tilting Range: 120º
Angle of Coverage: 140º with sneak-by guard
Sensor Swivelling Range: 180º
Sensor Tilting Range: 90º
Reach/Distance: 14 m max (temp. stabilised)
Response Brightness: 2 – 2,000 lx
Time Setting: 8 sec – 35 min
Overall Dimensions: Width 175 mm
Height 210 mm
Depth 180 mm
Net Weight 1200 g
Case Materials: UV Resistant Plastic
Aluminium Heat Sink

12W Sensor Switched LED Flood light Features:

Improved 12W model with same lumen output/brightness as previous 14.8W model
Suitable replacement for 150W halogen light
Cool White light output. Colour Temperature of 6700K
STEINEL – Long Life LEDSubstantial Energy Saving and very long life-span thanks to LED system
PIR (Passive Infra-Red) motion sensor – continuously scans a preset operating zone to switch ON LED floodlight when movement is detected
No mercury or other toxic content and No IR or UV radiation
Environmentally friendly Sustainable Lighting technology for the Green economy
STEINEL’s patented Active-Thermal-Control (ATC) cooling system which constantly monitors and regulates the temperature of the LEDs. This prevents over-heating and prolongs the life of the LEDs.
ENERGY EFFICIENCY – Made in GermanyElegant high quality design from Germany
Adjustable orientation of floodlight – Swivelling range of 180º and Tilting range of 120º
UV resistant plastic housing material
5 year guarantee – funtional warranty

Applications:
Energy Efficient Security lighting
Ideal for porches, driveways, courtyards, gardens and other amenity areas
Outdoor general illumination with elegance
Low maintenance “Fit and Forget” lighting applications

30W Blue LED Flood light

30W Blue LED Flood light

30W Blue LED Flood light  Shatter Resistant Tempered Glass Metallic Grey finish Classic design IP65 rated Lumen Output 2400 lm

30W Blue LED Flood light  Specification:

Power: 30W
Luminous Flux (Lumen): ≥2400 lm
Colour Designation: BLUE
Colour Temperature (Kelvin): BLUE
LED Technology: Bridgelux 30W LED chip
IP Rating (Ingress Protection): IP65
Input Voltage: 90 -260 VAC
Input Frequency: 47Hz – 63Hz
Input Power: ≤33W
Rated Lifetime: >30,000 hours
Beam Angle: 120° degrees
EU Energy Efficiency label: Class A
Mercury Content: 0 mg
Operating Temperature: -40ºC to +40ºC
Storage Temperature: -40ºC to +40ºC
Overall Dimensions: Length 225 mm
Width 185 mm
Height 130 mm
Net Weight 2.10 kg
Case Materials: Alumimium Alloy
Toughened Glass
Case Colour: Metallic Grey

30W Blue LED Flood light  Features:

BLUE light colour output
Substantial Energy Saving and very Low Maintenance
Advanced Bridgelux (USA) state-of-the-art LED chip technology – global market leading semiconductor LED chip manufacturer
IP65 rated for all-weather outdoor use and ROHS compliant
Environmentally friendly Sustainable Lighting technology for the Green economy
No mercury or other toxic content and No IR or UV radiation
Shatter resistant tempered glass
Flylead electrical cable of 1 metre
Adjustable bracket for light positioning/orientation
24 months warranty period for approved installations

Applications:
Exterior ambiance lighting
Wall washing
Domestic, municipal, commercial and industrial use
Landscape and gardening lighting
High level / Low maintenance “Fit and Forget” applications

LED explosion proof lamp application requirements increase

In recent years, due to increased demand for LED lamps to replace governments to actively support the relevant stickers, LED industrial lighting growing rapidly. TrendForce’s Green Energy Business Division LEDinside latest research report, in 2016 the global LED lighting industry market reached 2.932 billion US dollars, and more than 15% annual growth rate of growth, in 2020 the market size will reach $ 5.204 billion.

LED explosion proof lamp application requirements increase

Wherein, in the industrial lighting applications, due to the replacement demand-driven, the 2016 LED explosion proof lights market prospects. LED explosion proof lights use to prevent ignite an explosive mixture around, such as explosive gas, dust environment, methane gas. Specific measures taken their lamps are widely used in electrical special working environment, flammable and explosive dust. Thanks to petroleum and related industries, driven by explosion-proof lights in the field of industrial mining, petroleum, military, transportation and other large market position.

LED explosion proof lights for many years, companies in R & D have mastered more experience to develop generations of products to meet the basic requirements for use in hazardous locations. LED explosion proof lights a smaller volume than the traditional explosion-proof lamps, lighter weight, longer life, prices are more moderate, won the customer satisfaction. For the oil and petrochemical industry lighting places, such as considering the overall quality and safety performance of the project, cost control and future mercury repeal, which are selected ripe for explosion-proof LED light is the only way.

Proof lights depending on the environment protection standard equipment on the region, due to the continuous expansion of international trade exchanges, as the representative to the IEC standard electrical explosion-proof technology to get more and more applications in the world. Use of US electrical equipment, installation shall comply with the requirements of the United States Electrical Code NEC 500 / NEC 505, while there will be the competent authority (Authority Having Jurisdiction, AHJ) to the site audit. Other countries will adopt IEC and NEC 500 / NEC 505 as a reference, the corresponding device protection standards, such as the use of Chinese national standard GB3836.

20W SMD Cool White LED Flood light

20W SMD Cool White LED Flood light

20W SMD Cool White LED Flood light Grey & Black body new Slim design with SMD LED chips Lumen Output (Brightness) 1600 lm IP65 rated

20W SMD Cool White LED Flood light Specification:

Power: 20 W
Luminous Flux (Lumen): ≥1600 lm
Colour Designation: Cool White
Colour Temperature (Kelvin): 6000 K
Colour Rendering Index (CRI): ≥70
LED Technology: SMD
IP Rating (Ingress Protection): IP65
Input Voltage: 100 -240 VAC
Input Frequency: 50/60Hz
Rated Lifetime: >20,000 hours
Beam Angle: 100° degrees
EU Energy Efficiency label: Class A+
Mercury Content: 0 mg
Power Factor Correction: >0.95
Operating Temperature: -20ºC to +45ºC
Overall Dimensions: Length 142 mm
Width 36 mm
Height 182 mm
Net Weight 0.8 kg
Case Materials: Diecast Alumimium
Case Colour: Grey & Black

20W SMD Cool White LED Flood light Features:

New generation ultra SLIM design with SMD LED chips
Substantial Energy Saving and very Low Maintenance
50-70% reduction in energy use/cost compared to HP Sodium or Mercury Lamps and 80% lower on energy consumption compared to halogen or incandescent lamps
MEAN WELL – Power SuppliesThis LED floodlight utilises a driver by Mean Well – a global leader in power supplies
Cool White light. Colour Temperature: 6000K.
Ingress Protection Rating: IP65IP65 rated for outdoor use.
Environmentally friendly Sustainable Lighting technology for the new Green economy
No mercury or other toxic content and No IR or UV radiation.
Toughened glass and chrome reflector for smooth light.
V-TAC LED LIGHTING – ENERGY RATING A+Energy Rating: A+
Equivalent to 100W traditional incandescent lamp
Adjustable bracket for light positioning/orientation – 180º adjustability
Bulit-in constant current driver power supply – no external ballast required.
Versions of this LED floodlight also available in other lumen outputs (wattage) and other colour temperatures
V-TAC LED LIGHTING – 2 YEARS WARRANTYCovered in warranty for 2 years

50W Warm White LED Floodlight

50W-Warm-White-LED-Floodlight

50W Warm White LED Floodlight White housing in classic design IP65 rated Lumen Output 4000 lm

50W Warm White LED Floodlight Specification:

Power: 50W
Luminous Flux (Lumen): ≥4000 lm
Colour Designation: Warm/Neutral White
Colour Temperature (Kelvin): 3100 K
Colour Rendering Index (CRI): ≥80
LED Technology: Bridgelux 50W LED chip
IP Rating (Ingress Protection): IP65
Input Voltage: 90 -260 VAC
Input Frequency: 47Hz – 63Hz
Input Power: ≤33W
Rated Lifetime: 50,000 hours
Beam Angle: 120° degrees
EU Energy Efficiency label: Class A
Mercury Content: 0 mg
Operating Temperature: -40ºC to +40ºC
Storage Temperature: -40ºC to +40ºC
Overall Dimensions: Length 290 mm
Width 240 mm
Height 145 mm
Net Weight 2.80 kg
Case Materials: Alumimium Alloy
Toughened Glass
Case Colour: WHITE

50W Warm White LED Floodlight Features:

Substantial Energy Saving and very Low Maintenance
50-70% cost reduction compared to HP Sodium or Mercury Lamps and 80% lower on energy consumption compared to incandescent bulbs
BRIDGELUX – LED TECHNOLOGY3-5 times longer lifespan than sodium & 30 times longer than incandescent bulbs
Advanced Bridgelux (USA) state-of-the-art LED chip technology – global market leading semiconductor LED chip manufacturer
Warm/Neutral White light. Colour Temperature: 3100K. Colour Rendering Index (CRI): >80
IP65 rated for all-weather outdoor use and ROHS compliant
Environmentally friendly Sustainable Lighting technology for the Green economy
No mercury or other toxic content and No IR or UV radiation
Shatter resistant tempered glass
Flylead electrical cable of 1 metre
Adjustable bracket for light positioning/orientation
