LED 2in1 lamps – DULED 12 W/827 B22D
LED Floater Headline
. OSRAM GmbH.3 W in LED mode
Up to 80 % less energy consumption compared with ordinary light bulbs
Areas of application
Walkways and corridors
Children’s rooms
General illumination, Hallway and stairwell lighting
| Rated wattage | 12 W |
|---|---|
| Nominal wattage | 12 W |
| Nominal voltage | 220…240 V |
| Claimed equiv. conventional lamp power | 52 W |
| Rated power factor λ | 0.50 |
| Operating frequency | 50…60 Hz |
| Nominal luminous flux | 620 lm |
|---|---|
| Rated luminous flux | 620 lm |
| Color temperature | 2700 K |
| Color rendering index Ra | 80 |
| Starting time | 1.0 s |
| Warm-up time (60 %) | 13 s |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color as per EN 12464-1 | Warm White |
| Overall length | 130.0 mm |
|---|---|
| Diameter | 42.0 mm |
| Outer bulb | T9 |
| Lamp mercury content | 2.8 mg |
|---|---|
| Mercury-free | No |
| Nominal lamp life time | 6000 h |
|---|---|
| Rated lamp life time | 6000 h |
| Number of switching cycles | 10000 |
| Base (standard designation) | B22d |
|---|---|
| Footnote used only for product | All technical parameters apply to the entire lamp/Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value |
| Dimmable | No |
|---|
| EEI – Energy Label | A |
|---|
| ILCOS | FBT/DR-12-220-240-B22d-42/131 |
|---|---|
| Order reference | 85015-01 |
LED Floater Headline
. OSRAM GmbH.3 W in LED mode
Up to 80 % less energy consumption compared with ordinary light bulbs
Areas of application
Walkways and corridors
Children’s rooms
General illumination, Hallway and stairwell lighting
Flexible & calming
Application: night-time lighting and background lighting
Product features
Not suitable for use with dimmers
Family data sheet
Product family,
Lamps
LED 2in1 lamps
DULED
Inviting & safe
Application.
Company Press Career Sustainability
Back to OSRAM homepage
Applications
Products
Tools & Services
Trends & Knowledge
Advanced full-text search
Products – LED technology: important data at a glance
21 W/827 B22D
15 W/827 E27
12 W/827 B22D
15 W/827 B22D
12 W/827 E27
8 W/827 E27
21 W/827 E27
Scroll to left
Scroll to right
Zoom image
DULED 12 W/827 B22D
Product data sheet
Add to notepad
Technical data
Expand
Packaging information
Expand
Print this page
Jump to top
Global OSRAM websites OSRAM in the Social Web
Share Sitemap
Imprint Terms of use Privacy Policy Contact ? 2013: Children’s room lighting
G24 LED
Zoom in
Zoom out
Resize
Product benefits
Very low energy consumption of approximately 0: All rights reserved
| EAN code | Packaging unit Pieces per unit |
Dimensions l x w x h |
Gross weight | Volume |
|---|---|---|---|---|
| 4008321944726 | Blister 1 |
185 mm x 40 mm x 90 mm | 97.00 g | 0.67 dm³ |
| 4008321944733 | Shipping carton box 8 |
196 mm x 205 mm x 168 mm | 909.00 g | 6.75 dm³ |
| 4008321374363 | Shipping carton box 48 |
593 mm x 225 mm x 342 mm | 6282.00 g | 45.63 dm³ |
