Legend™ 412 RGBW quad color LEDs
and makes for better color rendering. The incorporation of white emitters increases the overall brightness, high performance moving yoke wash with 12 quad-colored RGBW Cree LEDs controllable in quadrants, dynamic chases and eye-candy pixel-mapping effects. while the calibration of LEDs ensures the visual uniformity of output, Nimble and ultra-compact,
, capable of an excellent wash. it is a multipurpose unit,Legend? 412 is an innovative
| • DMX connectors: 5-pin |
| • Pan & tilt: 630° / 200° |
| • Light source: 12 (10W) quad-color LEDs, 50,000 hours |
| • Configuration: 12 RGBW (700 mA per die) |
| • Strobe rate: 1 – 30 Hz |
| • Beam angle: 12° |
| • Field angle: 23° |
| • Illuminance: 1,500 lux @ 5 m |
| • AC Voltage Range: 100~240 V, 50/60 Hz (auto-ranging) |
| • Power Consumption 120 V, 60 Hz: 144 W, 1.8 A (operating) |
| • Power Consumption 230 V, 50 Hz: 139 W, 0.5 A (operating) |
| • Dimensions: 5.5 x 10.1 x 12 in (140 x 256 x 304 mm) |
| • Weight: 10.1 lbs (4.58 kg) |
| • Power Connection: IEC |
| • Environment: IP20, indoor/dry |
| • Certification: CE, MET |
12 channel – basic operation
28 channel – advanced operation with quaderent control
RGBW quad color LEDs
Electronic shutter
Electronic dimmer
All functions reset over DMX
Move in Black over DMX or on display
Movement Macros with speed adjustment
Color Macros with speed adjustment
Electronic power supply
IEC power cable
Fast movement
Bright quad color LED Stage Lights
Quadrant control of output
Strobe macros with quadrant strobe
Flicker free operation for HD cameras
:DMX channels: 12 or 28
Operating modes
