Using LED high bay brightness lighting requirements using manufacturers allow maximum current drive, but the average life expectancy of LEDs is highly dependent on temperature. Operating temperature rose by only 10 ° C can make life shortened by half. This situation forced designers to adjust the current must be reduced, sacrificing brightness to extend the service life. If required LED working under high ambient temperatures, the need to further reduce the current to minimize the environment to the chip temperature rise, in order to ensure the service life. However, due to the presence of the upper temperature limit, this will reduce the brightness of the illumination of the medium and low ambient temperature range. Essentially by lowering the brightness to achieve the work of high-temperature environments led smd.

LED array current is adjusted by the voltage of the detected current detection resistor R7, and is used as a feedback control of the controller, for example: TPS40211. The operational amplifier circuit (R9), to inject a current to the feedback node (FB) regulating current in order to reduce, or to increase the regulation current pour its current. FB node voltage is kept constant 0.26V. R7 voltage must be reduced to improve the voltage of the op-amp output (TP1), to obtain the compensation, so as to reduce the LED current. When the operational amplifier output just as 0.26V, the injection current is zero, while the LED adjustment will not be affected.

led smd and led heat sink



Thermistor RT1 is a negative temperature coefficient (NTC) devices. 25 ℃ It has a nominal resistance of 10K ohms, but the increase at -40 ℃ to 300K ohms or more, and at 100 ℃ are reduced to less than 1K ohm, and is in a nonlinear way. Resistors R8 and R10 5V bias voltage close FB voltage reduction, the value of R9 is to control the speed of the current reduced with the high temperature variations. The use of better adjusting the bias voltage is very important, because the accuracy of the circuit is subject to the influence of the bias tolerance. Resistors R9 must be placed as close to the current mode boost controllers placed, the purpose is to minimize the noise sensitivity. Use thermal epoxy the thermistor RT1 as close as possible to the central LED on the PWB connection led smd.

Only LED and thermistor in this temperature range. The thermistor detects the temperature is plotted as a graph, compared with the ambient temperature. We will calculate the obtained LED chip temperature is also plotted, which is equal to the temperature of the circuit board coupled to each LED of the power multiplied by the junction to the chassis (8 ° C / W) Thermal impedance. We can see that under high ambient temperature conditions, the operational amplifier circuit to reduce the LED current, the LED chip temperature close to the temperature of the LED circuit board. In this case, the temperature of the LED circuit board close to the ambient temperature, since the LED current is almost zero. This can be achieved LED chip temperature stability did not change. The RT1 nonlinear highest temperature LED current rapidly changing. The TP1 temperature “control voltage” also been drawn into the diagram, and well matched with the expected value led smd.



led smd down lights in shop applications

China’s National Development and Reform Commission since released the “China phased out incandescent roadmap” the roadmap requirements from October 1, 2012, prohibit the import and sale of 100 watts and above ordinary incandescent lighting, and is expected from 1 October 2016 date, banned the import and sale of 15 watts and above ordinary incandescent lighting, which means ordinary incandescent lighting has been phasing out the dust settles. With the gradual disappearance of incandescent, LED lights  led smd gradually emerge as a new force of energy conservation and environmental protection and well known.

led smd down lights in shop applications

In view of the rising price of fluorescent powder, ordinary energy costs continue to rise, and the upstart LED lights as the lighting gradually into the public view. Since the inception of the LED lights, constantly upgrading its brightness gradually from the G24 LED into the field of LED lighting. LED Downlight slowly from the high-end lighting upstart into the new darling of the application market.

The downlight general used in shopping malls, offices, factories, hospitals and other indoor lighting, installation is simple and convenient for people to love. LED Downlight inherits all the advantages of traditional downlight, heat a small, power-saving and long life and minimal maintenance costs. The early LED Downlight LED lamp beads expensive, the overall cost is very high not acceptable for customers. With the LED downlight chip price reduced cooling technology for LED downlight into the commercial field and laid a solid foundation.

LED Downlight LED lamp bulb downlight housing, as well as power. Downlight lamp beads should be used such as single 1W High Power LED lamp led smd beads, small power should not be used as 5050,5630 lamp beads, small power LED lamp bead brightness is bright enough and light enough strength, and the LED downlight general irradiation vertical distance of 4-5 meters, small power light is strong enough that not enough ground light intensity, and high-power lamp beads, especially the larger integrated light source light intensity became LED downlight manufacturer first. Commonly used high-power lamp beads such as single 1W lamp beads, made Downlight 1W, 3W, 5W, 7W, 9W, the largest general can be made 25W If using a high-power integrated solution can also do higher power.

Decided downlights life mainly of three parts: LED lamp beads led smd, LED heat dissipation the design of the shell, LED power. LED lamp beads manufacturers decided life LED downlight quality chip manufacturers.
