LEDs DECO FLEX BASE – Under cabinet lights – Indoor LED luminaires

LEDs DECO FLEX BASE – Under cabinet lights – Indoor LED luminairesLEDs DECO FLEX BASE - Under cabinet lights - Indoor LED luminaires



Electrical data
Nominal wattage 18.00 W
Nominal voltage 12.00 V
Mains frequency 50 Hz
Nominal current 1.50 A
Operating mode Electronic control gear (ECG)
Light technical data
Beam angle 113 °
Luminous flux 98.4 lm
Luminous intensity 0.866 cd
Color rendering index Ra 22.3
Dimensions & weight
Length 960.0 mm
Width 10.0 mm
Height 2.0 mm
Colors & materials
Body material Epoxy resin
Product color Transparent/White
Cover material Epoxy resin
Temperatures
Ambient temperature range …+25 °C
Additional product data
Number of lighting outlets 36
Equipment LED
Equipped with lamp Yes
Capabilities
Type of installation Adhesive
Adjustable Yes
Dimmable Yes
Color management (RGB) Yes
With on/off switch No
Accessories Control Unit / Remote control / Connection / Power plug
Certificates & standards
Standards CE
Protection class II
Type of protection IP20
Protection against ignition and fire F, MM
Country specific categorizations
Order reference 76123

LED Floater Headline
. bendable LED strips
Robust plastic profile
Color change
Equipment / Accessories
Plug & Light Set contains 3 LED strips. important data at a glance
RGB Add-on
BASE
Ext, remote control.
Company Press Career Sustainability
Back to OSRAM homepage
Applications
Products
Tools & Services
Trends & Knowledge

Advanced full-text search
Products – LED technology: Living room and dining room lighting
LEDs DECO FLEX

Zoom in
Zoom out
Resize
Product benefits
Efficient LED version
Can be cut to length to fit any shelving or any corner perfectly
Can be extended to an overall length of up to 3 m
Compact, very slim form factor
Easy to install and use
Areas of application
Compact spaces
Small coving
Shelf/furniture lighting
Living rooms
Sideboards
Display lighting
Glass cabinets
Wide spectrum of applications
Product features
Dimmable
Flexible, remote control, ECG and connectors
Add-on contains 2 LED strips and connectors Reduce text
Product benefits
Efficient LED version
Can be cut to length to fit any shelving or any corner perfectly
Can be extended to an overall length of up to 3 m
Compact, Kit
Zoom image
LEDs DECO FLEX BASE
Product data sheet
Add to notepad
Technical data
Expand
Graphics and application images
Expand
Product line drawing with numbersZoom image
Product line drawing with numbersZoom image
Product familyZoom image
Packaging imageZoom image
Application PicturesZoom image
Application PicturesZoom image
Application PicturesZoom image
Application PicturesZoom image
Application PicturesZoom image

very slim form factor
Easy to install and use
Areas of application
Compact spaces
Small coving
Shelf/furniture lighting
Living rooms
Sideboards
Display lighting
Glass cabinets
Wide spectrum of applications
Product features
Dimmable
Flexible,Product benefits
Efficient LED version
Can be cut to length to fit any shelving or any corner perfectly
Can be extended to an overall length of up to 3 m
Compact, bendable High Power LED Flood Light strips
Robust plastic profile
Color change
Packaging information
Expand
Country-specific information
Expand
Print this page
Jump to top
Global OSRAM websites OSRAM in the Social Web
Share Sitemap
Imprint Terms of use Privacy Policy Contact ? 2013, ECG and connectors
Add-on contains 2 LED strips and connectors Reduce text
Family data sheet
Product family, Hotel room lighting
Cosy & inviting
Application, bendable LED strips
Robust plastic profile
Color change
Equipment / Accessories
Plug & Light Set contains 3 LED strips, All rights reserved: very slim form factor
Easy to install and use
Areas of application
Compact spaces
Small coving
Shelf/furniture lighting
Living rooms
Sideboards
Display lighting
Glass cabinets
Wide spectrum of applications
Product features
Dimmable
Flexible: OSRAM GmbH:
Indoor High Power LED Flood Light luminaires
Under cabinet lights
LEDs DECO FLEX
Comfortable & variable
Application

LEDs DECO FLEX BASE – Deco & Living – Indoor LED luminaires

LEDs DECO FLEX BASE - Deco & Living - Indoor LED luminaires

Electrical data
Nominal wattage 18.00 W
Nominal voltage 12.00 V
Mains frequency 50 Hz
Nominal current 1.50 A
Operating mode Electronic control gear (ECG)
Light technical data
Beam angle 113 °
Luminous flux 98.4 lm
Luminous intensity 0.866 cd
Color rendering index Ra 22.3
Dimensions & weight
Length 960.0 mm
Width 10.0 mm
Height 2.0 mm
Colors & materials
Body material Epoxy resin
Product color Transparent/White
Cover material Epoxy resin
Temperatures
Ambient temperature range …+25 °C
Additional product data
Number of lighting outlets 36
Equipment LED
Equipped with lamp Yes
Capabilities
Type of installation Adhesive
Adjustable Yes
Dimmable Yes
Color management (RGB) Yes
With on/off switch No
Accessories Control Unit / Remote control / Connection / Power plug
Certificates & standards
Standards CE
Protection class II
Type of protection IP20
Protection against ignition and fire F, MM
Country specific categorizations
Order reference 76123

. very slim form factor
Easy to install and use
Areas of application
Compact spaces
Small coving
Shelf/furniture lighting
Living rooms
Sideboards
Display lighting
Glass cabinets
Wide spectrum of applications
Product features
Dimmable
Flexible.
Company Press Career Sustainability
Back to OSRAM homepage
Applications
Products
Tools & Services
Trends & Knowledge

Advanced full-text search
Products – LED technology,
Indoor LED luminaires
Deco & Living
LEDs DECO FLEX
Comfortable & variable
Application. Living room and dining room lighting
LEDs DECO FLEX

Zoom in
Zoom out
Resize
Product benefits
Efficient LED version
Can be cut to length to fit any shelving or any corner perfectly
Can be extended to an overall length of up to 3 m
Compact:, ECG and connectors
Add-on contains 2 LED strips and connectors Reduce text
Family data sheet
Product family, remote control, LED Floater Headline
, bendable LED strips
Robust plastic profile
Color change
Equipment / Accessories
Plug & Light Set contains 3 LED strips. very slim form factor
Easy to install and use
Areas of application
Compact spaces
Small coving
Shelf/furniture lighting
Living rooms
Sideboards
Display lighting
Glass cabinets
Wide spectrum of applications
Product features
Dimmable
Flexible. Hotel room lighting
Cosy & inviting
Application. bendable LED strips
Robust plastic profile
Color change [, All rights reserved, important data at a glance
RGB Add-on
BASE
Ext: OSRAM GmbH:] Show all
Product benefits
Efficient LED version
Can be cut to length to fit any shelving or any corner perfectly
Can be extended to an overall length of up to 3 m
Compact: Kit
Zoom image
LEDs DECO FLEX BASE
Product data sheet
Add to notepad
Technical data
Expand
Graphics and application images
Expand
Product line drawing with numbersZoom image
Product line drawing with numbersZoom image
Product familyZoom image
Packaging imageZoom image
Application PicturesZoom image
Application PicturesZoom image
Application PicturesZoom image
Application PicturesZoom image
Application PicturesZoom image
Packaging information
Expand
Country-specific information
Expand
Print this page
Jump to top
Global OSRAM websites OSRAM in the Social Web
Share Sitemap
Imprint Terms of use Privacy Policy Contact ? 2013

EAN code Packaging unit
Pieces per unit
Dimensions
l x w x h
Gross weight Volume
4008321524348 Role
1
263 mm x 100 mm x 100 mm 442.45 g 2.63 dm³
4008321524355 Shipping carton box
4
217 mm x 297 mm x 214 mm 2437.00 g 13.79 dm³
4008321524362 Shipping carton box
16
874 mm x 323 mm x 233 mm 10529.50 g 65.78 dm³
