Quality COB LED High Bay Light Industrial LED Lighting IP65 60 watt - 200 watt
Power: 60-200W
Voltage: 100-305VAC
Lumens: 6900-23000lm
Color: 3000K/4000K/5000K/5700K/6500K
Beam Angle: 25°/45°/60°/100°/120°
Warranty: 60 Months
COB Bulkhead LED High Bay Lights are a new product to Eneltec. As we are using CREE SMD3030, MEANWELL LED Driver, 5 years warranty, the cost are much lower. PF>0.95, CRI>70.
Professional design for Heat dissipation module structure, beautiful Appearance and contains the vents, internal & external ventilation, every fin form left to right passthrought convection channel,make 3D three-dimensional heat dissipating, maximum for heat dissipation.
Download the data and know more about our COB LED high bay light.
By using the Φ6mm heatpipe, the heat generated by the lighting quickly transfers to the cooling moduleof massive radiation fins, efficiently reduce the temperature of the LED lighting chips and extend thelifespan of the lighting source.
3D Heat Dissipation
Professional heat dissipation structure design. Modular heatsink withperfect structure and inside airflow channels maxim the 3D heatdissipation.
Patented HDT Technology
High efficient heatpipescontact the heat sourcedirectly, maximize theperformance of theheatpipe to reach thecooling effect.
Compressed Fins Technology
Rivet the heatpipe to heatsink body closely, minimize the heat resistance, greatly improve the heat dissipation effect, and it’s much lighter compared with similar products.
No. | Pictures | Model No. | LED Chips |
LED Driver |
Power (W) | Lumen (LM) | Beam Angle | Input Voltage |
1 | ENHB-60W-04CE | CREE SMD3030 60 pcs |
CE Approved | 60 | 6900 | 25°/45°/ 60°/100°/ 120° |
100-305VAC | |
2 | ENHB-60W-04MW | CREE SMD3030 60 pcs |
MEANWELL XBG-60-A | 60 | 6900 | 25°/45°/ 60°/100°/ 120° |
100-305VAC | |
3 | ENHB-100W-04CE | CREE SMD3030 100 pcs |
CE Approved | 100 | 11500 | 25°/45°/ 60°/100°/ 120° |
100-305VAC | |
4 | ENHB-100W-04MW | CREE SMD3030 100 pcs |
MEANWELL XBG-100-A | 100 | 11500 | 25°/45°/ 60°/100°/ 120° |
100-305VAC | |
5 | ENHB-150W-04CE | CREE SMD3030 154 pcs |
CE Approved | 150 | 17250 | 25°/45°/ 60°/100°/ 120° |
100-305VAC | |
6 | ENHB-150W-04MW | CREE SMD3030 154 pcs |
MEANWELL XBG-160-A | 150 | 17250 | 25°/45°/ 60°/100°/ 120° |
100-305VAC | |
7 | ENHB-200W-04CE | CREE SMD3030 203 pcs |
CE Approved | 200 | 23000 | 25°/45°/ 60°/100°/ 120° |
100-305VAC | |
8 | ENHB-200W-04MW | CREE SMD3030 203 pcs |
MEANWELL XBG-240-A | 200 | 23000 | 25°/45°/ 60°/100°/ 120° |
100-305VAC |
