作者：Blade

In-depth segmentation of LED smart home brands

In addition to traditional lighting companies and smart lighting companies, smart home brands also frequently appear in the smart lighting field, such as Oribo, Lumi, and so on. The reason why smart home brands continue to penetrate the field of smart lighting is not without reason.

In-depth segmentation of LED smart home brands

First, smart lighting is an important part of smart homes, and smart home brands can’t miss it. Nowadays, consumers’ acceptance of smart homes continues to increase, and the development trend of smart homes is improving, smart lighting is an important part of smart homes. Naturally, smart home brands will not give up this field. According to data from the China Smart Home Industry Alliance (CSHIA), smart lighting occupies a large market share in smart homes, reaching 16%, second only to home security. In this context, it is only natural for smart home brands to continue to make efforts in the field of smart lighting.

Second, the smart lighting products launched by smart home brands are easier to interconnect with other products of their own. Previously, with the influx of players from all walks of life into the smart home field, the brands and types of smart home products are also increasing. However, due to the different brands, it is difficult for smart home products of different brands to be interconnected. The home experience is also limited and incomplete.

Nowadays, more and more smart home brands are developing in the direction of whole-house intelligence in order to bring consumers a smarter and more comfortable smart home experience. The smart lighting products launched by the smart home brand are more closely connected with other smart home products of the brand, and it is easier to realize the linkage and interaction of the equipment. The stability and intelligence can be higher, and the user’s smart home experience can also be improved promote.

Third, smart home brands are continuing to improve the matrix of smart lighting products to meet the diverse smart lighting needs of users. Due to differences in user room types and habits, their requirements for smart lighting products are also different. Therefore, smart home brands are constantly improving the matrix of smart lighting products. For example, in the field of smart lighting alone, Oribo has launched a variety of smart lighting products. It is understood that Oribo has launched 8 categories, a total of 150 smart lighting products, and has successfully become the industry’s first in the subdivision track of “smart aimless lights”.

LED colorful lights applied in full-color LED light strips

The so-called LED full-color light strip refers to the assembly of LEDs on a strip-shaped FPC flexible circuit board or PCB hard board, which is named for its product shape like a strip. Both the full-color LED light strip and the magic light strip can control the changes of tricks such as single-light horse racing, running water, window opening, meteor chasing, and chasing. Any color can be displayed, and can be combined into any pattern at will, especially when it is made into a light bar screen.

LED colorful lights applied in full-color LED light strips

Both the full-color LED light strip and the magic color marquee light strip have rich and bright colors, high visibility, and visual appeal. It is widely used in wall corridors, indoor environment decoration, entertainment venues, bar backlights for wine cabinets, ceiling backlights, LED light box light sources, LED luminous signs, aquarium supplies, car decoration, etc. It is a new alternative to traditional neon lights, fluorescent lights, and lamps A generation of lighting sources.

Full-color LED light strips are more and more popular among consumers because of their energy-saving features, many patterns, dazzling changing effects, high brightness, reasonable price, wide application environment, and simple installation. Throughout the industry, everyone’s name or name for the full-color light strip is not uniform. The professional name is that the full-color LED light strip is also called the LED magic light strip.

Compared with the general light strips in the market, this product mainly has an extra driver IC on the FPC board. At the same time, there are certain standards for the copper requirements during the board manufacturing process. If the copper is not used properly during the manufacturing process, will seriously lead to product instability, so the convention is that the board requirements for full-color LED lights with 12V 30 lights will be above 2A copper on double-sided boards. 144 lights generally need to be above 2.5A copper.

LED full-color light strips and LED full-color light strips are generally universal, and both refer to flexible light strips; but magic light strips specifically refer to flexible light strips, that is, the light strips that use FPC as the circuit board. The light bar includes two kinds of soft light bar and hard light bar. One is to use FPC as the circuit board, and the other is to use the hardboard as the circuit board. The general standard of voltage used is DC 12V voltage, and some use 24V voltage. There are also custom-made ones, available for 6V and 9V. The common standard for light strips on the market is to use 12V voltage.

The lighting renovation of ordinary classrooms in Zhejiang Province reached 97% of the standard

Recently, the Zhejiang Educational Technology Center issued the “2022 Statistical Analysis of Educational Technology Equipment for Ordinary Primary and Secondary Schools in Zhejiang Province”.

The lighting renovation of ordinary classrooms in Zhejiang Province reached 97% of the standard

The “Statistical Analysis” pointed out that in 2022, the total investment in educational technology and equipment for ordinary primary and secondary schools in the province will be 5.952 billion yuan, a decrease of 518 million yuan from 2021, a year-on-year decrease of 8.01%.

“Statistical Analysis” also pointed out that from the perspective of the total investment in educational technology and equipment in ordinary primary and secondary schools in the province, from 2018 to 2022, the total investment has exceeded 5 billion yuan for five consecutive years. However, affected by factors such as the epidemic, fiscal austerity, and growth in demand from other sectors, the total investment in 2022 will decline compared with previous years, but the decline will be small. From the perspective of investment structure, investment in information technology equipment is still the main investment, in order to ensure online teaching under the epidemic situation, accelerate the improvement of regional education informatization level, improve the “bottom” of education modernization, and promote the quality and balance of urban and rural education.

According to the data, after the Zhejiang Provincial Department of Education promulgated the “Technical Specifications for Eye-protecting Lighting Retrofit Projects in Primary and Secondary Schools”, all localities actively standardized the implementation of eye-protective lighting renovation projects in primary and secondary schools, explored and promoted intelligent lighting in classrooms, and created a teaching environment that is conducive to the comprehensive prevention and control of myopia. Guarantee the healthy development of students. 97% of the province’s ordinary classrooms have met the lighting standards, and 58% of the ordinary classrooms are equipped with intelligent lighting.

The compilation of “Shanghai Green Lighting Development Report 2022” started

Thoroughly implement the requirements of the Ministry of Housing and Urban-Rural Development on further strengthening the green, low-carbon, and high-quality development of urban lighting during the “14th Five-Year Plan”, take green lighting as a foothold, summarize the work of road lighting and landscape lighting, and make a report on the development track and construction results of Shanghai’s green lighting A systematic summary to fully demonstrate the development of Shanghai’s urban lighting in 2022. At the same time, focuses on the future, scientifically studies the development trend of Shanghai’s green lighting, and provides a professional basis for urban lighting management decisions in the next stage. According to the relevant requirements of the Municipal Housing and Construction Commission and the Municipal Green Appearance Bureau, the Shanghai Green Building Association is responsible for compiling the “Shanghai Green Lighting Development Report 2022”. On July 20, 2023, the kick-off meeting for the preparation of the “Shanghai Green Lighting Development Report 2022” was held in the association. Zhang Yonggang, deputy director of Shanghai Municipal Commission of Housing and Urban-Rural Development, Miao Jun, second-level inspector of the Municipal Greening and City Appearance Bureau, and Cui Minghua, president of the association, attended the meeting and delivered speeches.

The compilation of "Shanghai Green Lighting Development Report 2022" started

The Facilities Management Office of the Shanghai Municipal Commission of Housing and Urban-rural Development, the Landscape Office of the Municipal Green Appearance Bureau, the Municipal Comprehensive Management Affairs Center, and the City Appearance and Landscape Affairs Center attended the meeting. Hengnengtai, Roman Lighting, Hongxin Power, China Electronics Technology, Shuzhu Technology, Qin Electric Information, Shanghai Guocheng Branch, Urban Lighting Company, East China Institute, Shanghai Institute, Municipal General Institute, Tongji Design Institute, Urban Construction Design Institute, Fudan Planning Institute, Environmental Institute, Tongji University, Bifu (bpi) Lighting, Unilumin Representatives of more than 20 participating units including science and technology participated in the meeting and exchanged speeches. The meeting was presided over by Zhu Jianhao, former first-level inspector of Shanghai Housing and Urban-Rural Construction Management Committee, and Zhang Jun, deputy secretary-general of the Shanghai Green Building Association, who attended the meeting.

At the meeting, Hengnengtai, the drafting unit of the report, introduced the preparation background, guiding ideology, preparation arrangement, and progress plan of the report. The report will fully reflect the overall development of the city’s green lighting in 2022, and systematically summarize the experience and achievements in the development process around “one main line” and “three bright spots”.

In his speech, Zhang Yonggang, deputy director of the Shanghai Municipal Commission of Housing and Urban-Rural Development, affirmed the achievements of the Shanghai Green Building Association in the preliminary work of the report, and put forward requirements for the follow-up work, emphasizing that the Shanghai Green Building Association should take the lead in making the general committee, the relevant departments of the committee and All relevant participating units must actively cooperate, and the editors must go all out to complete the editing tasks on time and with high quality, provide professional advice for the government to carry out urban green lighting work in the next stage, and promote high-quality urban development.

Chengdu completed the transformation of more than 100,000 LED light poles

It is understood that in order to match the various lighting management and maintenance needs in the main urban area of Chengdu, the Chengdu Lighting Internet of Things Big Data Center came into being. The platform can actively and accurately identify street lamp failure types, equipment identification, GIS geographic location, and other information. After receiving the fault information, the platform will classify the algorithm according to the road section, safety hazard, and fault category, dispatch it to the front-line maintenance personnel in the form of a work order, and collect and archive maintenance results to form efficient closed-loop management.

Chengdu completed the transformation of more than 100,000 LED light poles

“Giving ID cards to street lamps is not just as simple as pasting signs,” said the relevant person in charge of the platform. Location and other information give each main light pole a unique identity, and through digital twins, the light poles can truly ‘live’ with us in the streets and alleys of Chengdu.”

Up to now, more than 100,000 light poles have been transformed, more than 100,000 single light controllers have been installed, and more than 800 smart monitoring boxes have been replaced, so that all light poles with certificates can be connected to the “network”.

It is an “ID card” and a “medical insurance card”, and the street lamp can also be “registered” automatically.

After taking out the mobile phone to scan the QR code on the “ID card” of the street lamp, you can enter the “diagnosis” page of the lamp post – Chengdu Street Lamp Repair WeChat applet, which records basic information such as the number of the lamp post and the road where it is located.

“Citizens encounter street lamp failures in their lives, and can locate the faulty light pole by scanning the code. If the QR code cannot be scanned due to contamination or missing, they can also locate and report the fault through the small maintenance program. Compared with the traditional telephone fault reporting and repair applets can help us locate the fault point more accurately and quickly.” said the staff of Chengdu Lighting Internet of Things Big Data Center.

The staff member said that the front-line lighting operation and maintenance personnel are like “doctors” who specialize in the field of urban lighting. Every day they will carry out systematic inspections according to the plan, and the lighting problems they find and solve will also form a part of the city. Lighting “medical records”, according to the characteristics of these diseases, the lighting Internet of Things big data center will continue to optimize the daily inspection plan, forming a closed loop of inspection “diagnosis and treatment”.

The light pole transformation work completed before is also particularly important at this time. A variety of intelligent diagnosis and treatment equipment, including single-light controllers, intelligent monitoring boxes, and water-logging monitoring sensors, have been transformed and constructed to replace manual inspections. The networked big data center alarms, and generates a “registration list” according to the pre-configured alarm algorithm or through manual assignment, and automatically dispatches the front-line personnel to go for maintenance. When the equipment maintenance is completed, the system alarm recovers, forming a closed loop of intelligent perception and fault reporting.

Municipal lighting in Huishan District, Wuxi, Jiangsu

Street lights are dots of “starlight” that light up the night sky of the city, illuminating the road for citizens to travel safely at night.

Municipal lighting in Huishan District, Wuxi, Jiangsu

In recent years, with the development of urban and rural construction in Huishan District and the continuous improvement of the traffic road network, the mileage of urban roads in Huishan District, Wuxi City, Jiangsu Province has increased by leaps and bounds, and the energy consumption of street lamps has increased year by year. According to statistics, Huishan District currently has more than 45,000 municipal lighting street lamps, but more than 35,000 of them are still using high-pressure sodium lamps. There are problems such as unreasonable energy consumption, imprecise management, and low urban lighting level.

Since 2022, in order to systematically improve the status quo of municipal lighting, Huishan District has been based on the long-term, focused on the future, promoted high-quality development with firm reforms, and initiated the implementation of contract energy management for municipal lighting facilities in the district.

What are the aspects of contract energy management for lighting facilities?

1. LED Energy Saving Transformation

It is planned to use 2-3 years to invest 87 million yuan to carry out LED transformation and single-lamp controller installation for 35,000 municipal lighting street lights. “The application proportion and power saving rate are higher than the city’s level.

2. Lighting intelligent supervision

Utilizing mature technologies such as GIS and Sanyao, an intelligent supervision platform for municipal lighting facilities in the whole district is simultaneously established to realize “one-network unified management” of lighting facilities in districts, towns (streets), and villages (communities), and to realize the dynamic grasp of information by district authorities and Intervention management and assessment.

3. Adjust the management system

The lighting facilities after the energy-saving transformation will be fully taken over by the District State Control Group, which will unify the management and maintenance entities at all levels, making the scientific and technological means, personnel technology, mechanical equipment and other aspects highly specialized, and strive to build a professional municipal lighting maintenance team based in Huishan.

Benefits of energy management contracts

It is reported that contract energy management can not only solve a series of software and hardware problems in the municipal lighting industry in our district, but also produce obvious economic benefits. According to preliminary estimates, after the energy-saving transformation is completed, 160 million kilowatts of electricity can be saved in ten years During the ten-year contract period, it is estimated that the government will save 112 million yuan in electricity bills, and the electricity energy-saving benefits generated will be distributed by the district-level finance and the State Control Group in a certain proportion. Public lighting resources such as street light poles will also be deeply tapped by the State Control Group. The potential value is used to feed back the development of the municipal lighting industry in the whole region, and then realize the healthy development of the municipal lighting industry.

Hubei Wenquan Avenue, Huancheng North Road lighting project trial lights

At 8:00 p.m. on April 18, 120 sets of brand-new street lights on Wenquan Avenue and Huancheng North Road, Fang County, Shiyan City, Hubei Province began to shine in the night. state.

Hubei Wenquan Avenue, Huancheng North Road lighting project trial lights

The construction of road and street lighting facilities such as Wenquan Avenue and Huancheng North Road is a key project of the Fangxian government in 2023. It is also an important livelihood project to build a “4A” scenic county town, comprehensively improve the external image of Fangxian, and promote the development of the night economy in the central city.

As the traffic artery connecting several towns in the east, Wenquan Avenue plans to install 206 sets of double-pole and double-arm street lights and lay 6,000 meters of street light cables. Huancheng North Road has a total length of 6 kilometers. It is planned to install 255 sets of street lights and lay 12,000 meters of cables.

During the construction process, the Urban Management and Law Enforcement Bureau, in accordance with the requirements of the Fangxian County Party Committee and the County Government, urged the construction unit to seize the progress of the project, pay close attention to the quality of the project, and carry out the lighting renovation construction in strict accordance with the requirements of the design plan. Currently, the installation progress of the street lights on the two roads It has reached 80% of the total amount of the project. Next, the Fangxian Urban Management and Law Enforcement Bureau will go all out to organize the equipment and personnel, accelerate the project construction, and ensure that the lighting project is completed on schedule and with high quality.

Dalian Bay Submarine Tunnel Lighting System Lights Up

Recently, after 120 consecutive days of high-intensity fighting, the lighting system of the first cross-sea immersed tube tunnel in the high-latitude cold region of my country has been completely installed and debugged, and the interior of this submarine “giant dragon” has been fully lit.

Dalian Bay Submarine Tunnel Lighting System Lights Up

As a high-tech submarine lighting system, the artificial intelligence lighting of the Dalian Bay Submarine Tunnel in Dalian City, Liaoning Province can achieve harmony and unity with natural light, and can “feel” cloudy, sunny, cold, and warm, night and day – can adapt to the light perception of the four seasons change, timely adjust the color temperature and color difference between the seabed and the land area; adjust the brightness of the seabed light in time according to different weather such as sunny, cloudy, rainy, snowy, foggy, etc., as well as different light intensities such as morning, evening, daytime, and nighttime “High EQ” two-in-one.

To light up such a huge “dragon” on the seabed, there are many types of lighting that need to be set up – basic lighting in the middle section of the main line of the tunnel/ramp, emergency lighting, enhanced lighting at entrances and exits, lighting for awnings, passage lighting, and lighting in equipment rooms etc.; there are more than 10,000 sets of lighting fixtures alone, and the total length of the laid circuit is nearly 420,000 meters, involving nearly 180,000 meters of power pipelines, and nearly 10,000 sets of hangers…

At the same time, a strong power supply system is also required to support one lighting power distribution room and emergency lighting power supply room are respectively set up in the north bank equipment area of the tunnel, the south bank equipment area (1), and the south bank equipment area (2). Install 2 lighting equipment platforms. The lighting distribution room is equipped with a lighting distribution cabinet, an intelligent lighting control cabinet, and a lighting distribution box in the equipment area. The emergency lighting power supply room is equipped with a centralized emergency power supply device and a type A emergency lighting centralized power supply. A 10kV/ 0.4kV buried transformer for lighting, lighting distribution cabinet, intelligent lighting control cabinet, centralized emergency power supply device, and A-type emergency lighting centralized power supply.

Such a complicated submarine lighting system installation project is faced with difficulties such as time constraints, heavy tasks, and cross-operations. Especially for the lighting installation of the arc section of the submarine tunnel, it is necessary to convert the distance of the center line of the road into the distance of the inner arc and the outer arc before construction. , In addition, the installation of lamps and lanterns is a high-altitude operation, which is more dangerous. The Dalian Bay Submarine Tunnel Electromechanical Team of the China Communications First Harbor Engineering Co., Ltd.’s installation company faced difficulties head-on and took measures such as advanced layout, process coordination, and precise debugging to ensure quality and quality with the construction rhythm of “all-weather operations” such as non-stop holidays and shifts during the day and night. Quantitatively promote the construction progress. In the end, the important project node of lighting installation and commissioning for the entire tunnel was successfully realized.

This submarine “dragon” was successfully lit up, marking another crucial step towards the goal of opening the Dalian Bay Submarine Tunnel on time.

More than 220,000 street lights in Tainan City were replaced with LED lights

Tainan City is divided into 3 districts to install LED street lights. At present, about 10,200 street lights in Xibei, the third district, are actively replacing. It is expected to complete more than 220,000 streetlights in the city as early as the end of June. Save 60% of electricity consumption and reduce carbon emissions by 50,000 tons. According to the Public Works Bureau, LED lamps are energy-efficient, brighter, and have a lower failure rate than traditional street lamps. They can save the city about 95 million yuan in electricity bills each year, and they have a 9-year warranty.

More than 220,000 street lights in Tainan City were replaced with LED lights

According to the Public Works Bureau, Nanshi’s street lamps have replaced old energy-consuming sodium lamps with LED lamps. After the “Project Plan for Expanding the Installation of LED Street Lights” in 2013 and the “Sunset Project for Mercury Street Lights” in 2016, it will continue from December 2021 to Execute the “Tainan City Replacement LED Street Lighting Construction Project” to replace the remaining about 100,000 old energy-consuming sodium gas lamps and fluorescent lamps with LED lamps. The total cost is about 885 million yuan, and it is divided into three areas. At present, about 70,000 LED street lights in Districts 1 and 2 have been replaced with LED street lights, and there are still more than 10,200 street lights in Xibei District 3 that are actively being refitted.

Mayor Huang Weizhe said that the construction and management of street lamps is an important basis for providing citizens with a safer living environment. With the replacement of LED street lamps, not only electricity bills can be saved, but also energy saving and carbon reduction can be achieved. In addition, through intelligent Monitor the status of street lights in real-time, and save administrative procedures and maintenance costs at the same time. In the past, street lamps used more power-consuming sodium gas lamps. Because the operating temperature was as high as 400 degrees, a lot of energy was wasted due to high heat. After years of hard work by the Nanshi government, Datainan street lamps will soon be able to fully use LED lamps.

According to the Public Works Bureau, in addition to replacing the old energy-consuming sodium gas lamps, the construction project of LED street lamps in Tainan City also built the “Tainan Smart Street Lighting Management System” with new technological functions, among which 10,000 smart street lights will be automatically detected, and if there is an abnormal situation, they can automatically report for repairs, which can shorten the repair time for lamp failures and ensure the safety of passers-by.

The landscape lighting project of Haisu Cultural Square in Changning District, Shanghai was successfully completed

Recently, the landscape lighting system of Haisu Cultural Plaza in Changning District has been commissioned and passed the project completion acceptance.

The landscape lighting project of Haisu Cultural Square in Changning District, Shanghai was successfully completed

As an important gathering place of culture, commerce and art in Changning District, Haisu Cultural Square is connected to Liu Haisu Art Museum, Haisu Green Space, Tianshan Park, light rail and other public venues and transportation hubs. In the overall night scene creation, combined with Haisu Cultural Square the fa?ade shape, with the meaning of mountains and rocks, echoes with Liu Haisu Art Museum, and jointly builds a cultural landmark with undulating mountains. The roof of the building has the highest brightness, followed by the entrances and exits and nodes, and the green landscape has the lowest brightness. Landscape lights are used to coordinate and integrate all blocks to the greatest extent.

The overall color temperature of the landscape lighting in Haisu Cultural Square is comfortable and pleasant, and the appropriate color lighting in the trendy blocks of the commercial space and the open-air square effectively enhances the commercial atmosphere.

The commercial block also incorporates high-tech interactive lighting, which perfectly combines art and commerce.

Gemdale Xinhua Road

Recently, the “Golden Land Xinhua Road” commercial office space project located on the west side of Shangsheng Xinsuo, Xinhua Road Street, was completed and opened. Since the start of construction, the District Greening and City Appearance Bureau’s Lighting Division has maintained linkage with businesses, actively doing a good job in the review and acceptance of lighting projects, and further exerting the role of “cohesion” in cohesion, service, and empowerment.

Xinhua Road is a long building with a total length of nearly 200 meters. The design style reveals minimalist aesthetics, and the thick stone on the facade creates a sense of time imprint.

When the lights come on, the lights of Xinhua Road are quiet, elegant, stable and grand. The overall building is presented in 3000K warm colors, blending in with the surrounding environment. The RGBW dimming and color changing system is turned on on weekends and holidays to increase the leisure atmosphere, which complements Shangsheng Xinsuo. The west facade of the building faces the residential buildings. In order to reduce the impact on the surrounding residents, lighting methods such as internal light transmission, slit lighting, window frame and overhanging lighting are mainly used to enhance the sense of three-dimensionality and lines.

Zhoupu Xieyang Culture and Leisure Corridor

Zhoupu Xieyang Cultural and Leisure Corridor is located at Lane 185, Quankou Road, Xinjing Town. It is a beautiful neighborhood with a miniature of old Shanghai and historical and cultural heritage. The night view of Zhoupu Xieyang enriches the urban slow traffic system, is an organic unity of living space, cultural space, and ecological space, and is a continuation of the beautiful scenery of Xinjing Town. Last year, the District Landscape Institute carefully organized maintenance units to comprehensively update the landscape lighting of Zhoupu Xieyang through the mode of maintenance and construction through landscape lighting.

Through the construction of landscape lighting, the cultural landscape wall and corridors are clearly layered, and people can feel the “past and present” of Xinjing Town on the landscape wall while strolling in the natural and comfortable night scene.

The image building of Zhoupu Xieyang has “Jiangnan rhyme”. Landscape lights with different color temperatures are randomly interspersed, which not only satisfies functional lighting, but also awakens the vitality of the building at night.

Along the walls of Jiangnan-style residences, the figure sculptures are designed vividly, adding to the fun of the space. Through the projection of lights, the humanistic life atmosphere in the regional environment can be better highlighted, and it has become a scenic spot for people to stop and watch.

The antique door shape, through the blessing of lights, uses the most natural method to highlight its three-dimensional effect, and the beautiful outline of the ancient building is clearly presented at night.

The landscape corridor at night not only satisfies practical and functional lighting, but also satisfies the creation of a comfortable and comfortable night environment atmosphere, providing surrounding residents with a public space for interaction and communication at night.

The orderly array of transparent and concise small light boxes on the cultural wall displays artworks and peasant paintings of various shapes, which not only play a role in promoting classic culture, but also make the entire wall come alive. The reporter learned that at present, the first phase of Zhoujiabang waterfront public space is being renovated and upgraded, and will be reopened to the public after the renovation is completed.
